KULIČKOVÉ ŠROUBY KUŘIM, a.s.

Ground ball screws

Thread diameter：12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125mm

Lead：3, 4, 5, 6, 8, 10, 12, 15, 16, 20, 24, 25, 30, 32, 40 , 50 mm

Maximum length of the shaft：6200 mm

Accuracy class：IT1, IT3 , IT5

Nuts：Preloaded nut and nut with backlash

Whirled ball screws

Thread diameter：40, 50, 63, 80, 100 mm

Lead：10, 12, 15, 16, 20, 24, 25, 30, 32, 40

Maximum length of the shaft：10000 mm

Accuracy class： IT5

Nuts：Preloaded nut and nut with backlash

Rolled ball screws

Thread diameter：12, 16, 20, 25, 32, 40, 50, 63 mm

Lead：4, 5, 10, 20 mm

Maximum length of the shaft：6200 mm

Accuracy class： T5

Nuts：Nut with backlash

Telescopic ball screw

Shaft diameters:80,100,125mm

Stroke height at one revolution:48mm

Minimum length:780mm

Maximum length:1580mm Dynamic capacity:Ca = 85 kN

Static capacity:Co= 280 kN

STANDART POSITIONING BALL SCREWS (ST)

Thread diameter：12 - 125 mm

Pitch： 3 - 50 mm

Maximum length： 12 m Precision class： IT1, IT3 a IT5 (T5)

Nuts :A, A+A, AP, AP+A, APR, B+B+K

Advantages：Universal application and wide range

HIGH-EFFICIENCY BALL SCREWS (HE)

Thread diameter：12 - 63 mm

Recommended pitch to 10 mm

Precision class：IT1, IT3 a IT5

Nuts：A, A+A, AP, AP+A, APR, AP+A "Segment recirculation

Advantages：High efficiency, hybrid construction

BALL SCREWS WITH A DRIVEN NUT

Thread diameter :50 - 80 mm

Pitch :20 - 32 mm

Precision class: IT1, IT3 a IT5

Nuts :RMV, RMI

Advantages：Energy saving

Ball screws are manufactured in Kuřim from the beginning of 70th, till 1996 they were manufactured in TOS KUŘIM. The company was privatized in 1996 under name TOS KUŘIM-KŠ, s.r.o. and in 1997the name of the company changed to KULIČKOVÉ ŠROUBY KUŘIM.Ball screws are manufactured in precision class IT1, IT3 and IT5 according to ISO and DIN standards and they meet the most demanding requirements of design of machine tools, automatic lines, special-purpose machines, consisting in technical parameters of rigidity, durability, high efficiency and smooth running. KULIČKOVÉ ŠROUBY KUŘIM manufactures and supplies the trapezoidal screws for conventional machine tools and for application on another industrial branch.
